Eaton
Eaton 9SX 3000VA / 2700W Rackmount Online UPS
Pickup available at NexGen Computing
Usually ready in 24 hours
Reliable, High-Performance Power for Critical Systems
The Eaton 9SX 3000I Rack2U is a high-performance UPS that provides reliable power protection for your critical equipment. With its online double-conversion topology, this UPS constantly monitors power conditions to regulate both voltage and frequency, ensuring a clean and stable power supply. It delivers 3000VA and 2700W of power, making it ideal for servers, networking devices, storage systems, and other IT infrastructure. The 0.9 power factor allows it to protect more equipment, saving you space and cost.
Advanced Battery Management and Runtime
Featuring Eaton's ABM® battery management technology, the 9SX extends battery life by up to 50% using an innovative three-stage charging technique. The system includes hot-swappable internal batteries and offers the capability to add up to four external battery modules for extended runtime during prolonged outages. The multilingual graphical LCD display provides clear information on the UPS's status, including battery health and estimated runtime, so you're always informed.
Seamless Integration and Management
Designed for easy integration, this 2U rackmount UPS comes with all necessary mounting hardware. It offers multiple communication options, including USB and RS232 serial ports, as well as a slot for an optional network card for remote monitoring and management. The Eaton 9SX is compatible with Eaton's Intelligent Power® Software, which seamlessly integrates with leading virtualization environments. Load segment control allows for prioritized shutdown of non-essential equipment to maximize battery runtime for your most critical devices.
Technical Specifications
| General | |
| Product Name | Eaton 9SX UPS |
| Catalog Number | 9SX3000IR |
| Topology | Online/Double-conversion with Power Factor Correction (PFC) system |
| Configuration | Rackmount 2U |
| Rating (VA/Watts) | 3000 VA / 2700 W |
| Electrical Input | |
| Input Connection | C20 |
| Nominal Voltage | 230V default (200/208/220/230/240/250V) |
| Voltage Range | 200-276 Vac without derating (up to 140-276 Vac with derating) |
| Frequency | 50/60 Hz (40-70 Hz range) |
| Input Power Factor | >.99 |
| Electrical Output | |
| Output Receptacles | (8) C13, (1) C19 |
| Nominal Voltage | 230V default (200/208/220/230/240V) |
| Output Power Factor | 0.9 |
| Output Waveform | Sine wave |
| Battery | |
| Battery Type | Sealed, lead-acid |
| Battery Management | ABM & Temperature compensated charging, automatic battery test, deep discharge protection |
| Battery Replacement | Hot-swappable internal batteries |
| Extended Battery Capability | Yes, supports external battery modules (EBM) |
| Communications | |
| User Interface | Multilingual graphical LCD display |
| Communication Ports | 1 USB port, 1 RS232 serial port, mini-terminal block for remote power off |
| Expansion Slot | One slot for optional communication card (e.g., Network-M2) |
| Physical | |
| Dimensions (H x W x D) | 86.5 x 438 x 608 mm |
| Weight | 26.5 kg |
| Environmental | |
| Operating Temperature | 0° to 40°C (32° to 104°F) |
| Noise Level | <45 dB at 1 meter |
| Relative Humidity | 0-96% non-condensing |
| Package Contents | |
| UPS, Input cable, (2) IEC-IEC output cables, USB cable, Serial cable, Rack-mounting kit, Safety instructions, Quickstart guide | |
Manufacturer Technical Data
| Product Spec Sheet | Not available for this product |
|---|
