TP-Link MC110CS 100BASE-FX to 100BASE-TX Single-Mode Media Converter (20km, SC/RJ45)
Pickup available at NexGen Computing
Usually ready in 24 hours
Bridge Copper and Fiber Networks Over Extreme Distances
The TP-Link MC110CS is a high-performance media converter engineered to seamlessly convert 100BASE-FX single-mode fiber to 100Base-TX copper Ethernet, or vice versa. It is the ideal solution for extending network connections over vast distances, capable of transmitting data up to 20 kilometers (12.4 miles) using single-mode fiber optic cable. This device is perfect for connecting remote buildings, deploying long-distance surveillance, or extending your LAN into areas unreachable by standard copper wiring.
Reliable, High-Speed Performance
Designed to meet IEEE 802.3u 10/100Base-TX and 100Base-FX standards, the MC110CS ensures broad compatibility and reliable performance. It supports a full wire-speed forwarding rate and operates on a 1310nm wavelength for both transmitting and receiving data, ensuring stable and consistent communication. The converter features auto-negotiation on the 10/100Mbps RJ45 port, automatically detecting and setting the optimal speed and duplex mode (Half/Full-Duplex). Additionally, advanced features like Link Fault Passthrough and Far End Fault work together to minimize data loss by providing timely link failure detection.
Flexible and User-Friendly Design
The MC110CS offers exceptional flexibility for any network environment. It can be used as a standalone device right out of the box or installed into TP-Link's 19-inch system chassis for larger, rack-mounted deployments. The front panel features easy-to-view LED indicators that provide real-time status updates for power and network activity, simplifying installation and troubleshooting. With Auto MDI/MDI-X support on the TX port, there's no need for crossover cables, further streamlining the setup process.
| MEDIA CONVERTER & MODULE | |
| Standards and Protocols | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Basic Function | Half/Full-Duplex transfer mode for FX port, Full Duplex Flow Control (IEEE 802.3x), Half Duplex Flow Control (Backpressure), Link Fault Passthrough and Far End Fault, Extends fiber distance up to 20km |
| Ports | 1 x 100M SC/UPC port, 1 x 10/100M RJ45 port (Auto MDI/MDIX) |
| Wave Length | 1310nm |
| Network Media 10BASE-T | UTP category 3, 4, 5 cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m) |
| Network Media 100BASE-T | UTP category 5, 5e cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m) |
| Network Media 100BASE-FX | Single-mode Fiber |
| LED Indicators | PWR, Link/Act |
| Dimensions (W*D*H) | 3.7 x 2.9 x 1.1 in. (94.5 x 73.0 x 27.0 mm) |
| Power Supply | External Power Adapter |
| Max Power Consumption | 2.4W |
| Safety & Emission | FCC, CE, RoHS |
| ENVIRONMENT | |
| Operating Temperature | 0℃~40℃ (32℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
Manufacturer Technical Data
| Product Spec Sheet |
 Download |
|---|
