Apc
APC Smart UPS On Line 20KVA 20KW Rack Tower 230V 380V
Pickup available at NexGen Computing
Usually ready in 24 hours
Power reliability for critical systems — the APC Smart-UPS On-Line 20KVA/20KW provides robust, double-conversion online power with a flexible rack or tower footprint. Ideal for servers, networking equipment, and storage devices, this unit delivers clean, continuous power to minimize downtime.
Designed for professional data centers and network rooms, it supports 230V / 380-415V configurations and offers hard-wired connections for a secure, maintenance-friendly setup. A built-in Network Card enables remote monitoring and management, while the rail kit is excluded for customized installation options.
Key features
- 20 kVA / 20 kW capacity for critical workloads
- Rack/tower form factor for flexible deployment
- Supports 230V and 380-415V input configurations
- Hard-wired connections: 5-wire (3P+N+E) + 3-wire (1P+N+E) configurations
- Network Card included for remote management
- Rail kit excluded
Specifications
- Model: APC Smart-UPS On-Line 20KVA/20KW – Rack/Tower
- Voltage configuration: 230V / 380-415V
- Hard-wired connections: 5-wire (3P+N+E) + 3-wire (1P+N+E)
- Network management: Network Card included
- Rail kit: Excluded
| Input current Total Harmonic Distortion (THD) | 5 |
|---|---|
| Battery recharge time | 4 |
| Battery life (max) | 5 |
| Audible alarm modes | Alarm when on battery,Low battery alarm,Overload alarm |
| Audible alarm(s) | Y |
| Surge protection | Y |
| LED indicators | Y |
| International Protection (IP) code | IP20 |
| SmartSlot | Y |
| Emergency Power Off (EPO) | Y |
| Auto-restart | Y |
| Cold start | Y |
| Crest factor | 3:1 |
| Non-operating altitude | 0 - 15240 |
| Harmonized System (HS) code | 85078000 |
| Width | 440 |
| Depth | 700 |
| Operating altitude | 0 - 2011.68 |
| Product colour | Black |
| Storage relative humidity (H-H) | 0 - 95 |
| Operating relative humidity (H-H) | 0 - 95 |
| Storage temperature (T-T) | -15 - 45 |
| Operating temperature (T-T) | 0 - 40 |
| Input operation voltage (min) | 160 |
| Output operation voltage (max) | 230 |
| Input frequency | 40/70 |
| UPS topology | Double-conversion (Online) |
| Waveform | Sine |
| Output frequency | 50/60 |
| Display type | LCD |
| Efficiency | 93 |
| Serial interface type | RS-232 |
| Serial interface | Y |
| USB port | Y |
| Form factor | Rackmount/Tower |
| Battery technology | Sealed Lead Acid (VRLA) |
| Package width | 590 |
| Package depth | 790 |
| Cables included | RS-232 |
| Output power capacity | 20 |
| Output frequency regulation | 0.1 |
| Noise level | 58 |
| Number of output phases | 3 |
| Input operation voltage (max) | 415 |
| Package height | 535 |
| Height | 306 |
| Battery voltage | 192 |
| Weight | 142500 |
| Maximum current | 87 |
| Output power | 20000 |
Product Specification Sheet
| Product Spec Sheet | Not available for this product |
|---|
