Aruba AP-505 RW Unified Access Point Enterprise Managed
Pickup available at NexGen Computing
Usually ready in 24 hours
The ARUBA AP-505 (RW) Unified AP is an enterprise-grade wireless access point designed to deliver reliable, secure Wi‑Fi in dense environments. As part of Aruba’s Unified AP portfolio, the AP-505 combines modern wireless technology with centralized management to support scalable, cloud-ready networks for small and mid-size deployments.
Built for RoW (Rest of World) regions, this compact device provides robust performance for classrooms, office suites, retail floors, and hospitality spaces. It integrates seamlessly with Aruba Central for cloud-based management or can be deployed with traditional on‑premises mobility controllers, offering flexible control as your network grows.
Key benefits include improved network efficiency through Wi‑Fi 6 technology, consistent user experiences with fast roaming, and simplified installation via PoE power and versatile mounting options. The AP-505 is designed to minimize cabling and downtime while delivering secure, policy-driven access for employees, guests, and IoT devices.
Key Features
- Wi‑Fi 6 (802.11ax) technology for better efficiency in high-density environments
- Dual-band operation on 2.4 GHz and 5 GHz with concurrent channels
- 2x2 MU‑MIMO (per band) to improve client capacity and performance
- Integrated security with modern encryption and guest access capabilities
- Cloud or on‑premises management via Aruba Central or Aruba Mobility Controllers
- Power over Ethernet (PoE) powered to simplify installation (IEEE 802.3af/at compatible)
- Compact, versatile form factor suitable for ceiling or wall mounting
Specifications
- Model: ARUBA AP-505 (RW) Unified AP
- Wi‑Fi Standard: 802.11ax (Wi‑Fi 6)
- Radio Bands: 2.4 GHz and 5 GHz (dual-band)
- Antenna Configuration: Internal, dual-band MIMO
- Maximum MIMO: 2×2 MU‑MIMO per band
- Ethernet: 1× 1 GbE PoE-capable port
- Power: PoE (IEEE 802.3af/at) capable
- Management: Aruba Central cloud management or on‑premises Mobility Controller
- Security: WPA2/WPA3 support, enterprise-grade encryption, guest access
- Deployment: Indoor, RoW region; ceiling or wall mounting
- Certifications: Typical safety and regulatory certifications for regional markets
- Environment: Built for use in office, educational, retail, and hospitality spaces; designed for steady operation in typical indoor climates
| Cable lock slot type | Kensington |
|---|---|
| Product colour | White |
| Cable lock slot | Y |
| Power over Ethernet (PoE) | Y |
| Antenna features | Integrated antenna |
| Operating temperature (T-T) | 0 - 50 |
| Operating relative humidity (H-H) | 5 - 93 |
| USB connector type | USB Type-A |
| Ethernet LAN data rates | 10,100,1000 |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| MIMO | Y |
| Weight | 500 |
| Width | 160 |
| Harmonized System (HS) code | 85176990 |
| Storage temperature (T-T) | -40 - 70 |
| Height | 37 |
| 5 GHz | Y |
| Placement | Ceiling,Wall |
| 2.4 GHz | Y |
| Auto MDI/MDI-X | Y |
| Maximum data transfer rate (5 GHz) | 1200 |
| MIMO type | Multi User MIMO |
| Antenna direction type | Omni-directional |
| Maximum data transfer rate (2.4 GHz) | 574 |
| Antenna type | Internal |
| Storage relative humidity (H-H) | 5 - 93 |
| Maximum data transfer rate | 1774 |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az |
| Depth | 161 |
| Spread spectrum method | DSSS,OFDM,OFDMA |
| Modulation | 16-QAM,64-QAM,256-QAM,1024-QAM,BPSK,CCK,QPSK |
| Power consumption (max) | 16.5 |
| Security algorithms | WPA3,WPA,WPA2 |
| Antennas quantity | 2 |
