RF Elements
RF Elements UltraDish TP 29 29dBi Wideband Parabolic Antenna
Pickup available at NexGen Computing
Usually ready in 24 hours
Unleash Unprecedented Performance with the RF Elements UltraDish TP 29dBi Wideband Antenna
Engineered for premium Customer Premise Equipment (CPE) applications, the RF Elements UltraDish TP 29dBi Wideband is a high-gain parabolic dish antenna designed to deliver exceptional performance across both 5 GHz and 6 GHz unlicensed bands. This antenna is the ultimate solution for service providers demanding increased gain, high directivity, and reliable link stability in high-noise environments. Its optimized radiation pattern with suppressed side lobes significantly reduces interference, ensuring a clean signal and robust connectivity.
Key Features & Benefits:
- Extensive Wideband Coverage: With an impressive frequency range of 4900 - 7125 MHz, this antenna provides excellent investment protection and flexibility, covering U-NII-1 to U-NII-7 bands.
- High-Gain 29dBi Performance: Achieve superior link performance and distance with a stable, high-gain signal across the entire operational band.
- Revolutionary TwistPort™ Connector: Featuring RF Elements' proprietary quick-locking waveguide port, the TwistPort™ connector ensures a lossless connection and makes radio installation and replacement incredibly simple and efficient.
- Superior Noise Rejection: The antenna's design focuses on high directivity and suppressed side lobes, minimizing collected and transmitted interference, which is crucial for stable performance in crowded RF areas.
- Built to Last: Constructed from corrosion-resistant materials like marine-grade aluminum and stainless steel hardware, the UltraDish is built to withstand harsh weather conditions, boasting an IP65 environmental rating and 160 km/h wind survival.
- Cross-Platform Compatibility: Seamlessly integrate with a variety of third-party radios using RF Elements' extensive line of TwistPort™ Adaptors for maximum versatility.
Comprehensive Technical Specifications
| Specification | Details |
|---|---|
| Antenna Connection | TwistPort™ - Quick Locking Waveguide Port |
| Antenna Type | Parabolic Dish |
| Frequency Range | 4900 - 7125 MHz |
| Gain | 29 dBi |
| Azimuth Beam Width -6dB | H 7.6° / V 7.6° |
| Elevation Beam Width -6dB | H 7.6° / V 7.6° |
| Front-to-Back Ratio | 40 dB |
| Polarization | Dual Linear H + V |
| Pole Mounting Diameter | 40 - 80 mm |
| Wind Survival | 160 Km/h |
| Environmental Rating | IP65 |
| Operating Temperature | -40°C to +60°C (-40°F to +140°F) |
| Dimensions | 735 x 735 x 185 mm |
| Weight | 4.2 kg / 9.2 lbs |
Manufacturer Technical Data
| Product Spec Sheet |
 Download |
|---|
