Ubiquiti
Ubiquiti UISP airFiber 24GHz PtP Radio Includes POE Injector | AF-24
Pickup available at NexGen Computing
Usually ready in 24 hours
Revolutionary Wireless Performance for High-Performance Backhauls
Experience a breakthrough in 24 GHz backhaul technology with the Ubiquiti airFiber AF-24. Housed in a compact and highly efficient form factor, the airFiber AF-24 is engineered to deliver revolutionary performance, achieving an aggregate throughput of over 1.4 Gbps and a range of up to 13+ km. This device ushers in a new era of price-disruptive, carrier-class backhaul technology, making it the ideal solution for PtP bridging and network backhauls. Surpassing the capabilities of conventional wired backhauls, the airFiber AF-24 provides the speed and reliability needed to handle demanding data traffic, capable of transmitting a 100 MB file in less than a second.
Engineered for Efficiency and Robust Performance
Every detail of the airFiber AF-24, from its silicon chip to its innovative split-antenna architecture, was meticulously designed by Ubiquiti's R&D team. It features an innovative dual-antenna architecture with separate, integrated transmit (TX) and receive (RX) antennas. This design eliminates the RF losses commonly found in systems where the RF signal is compromised by switches and filters, resulting in a more robust link budget, a better noise figure, and higher transmit power efficiency. The airFiber AF-24 supports both FDD (Frequency Division Duplexing) and HDD (Hybrid Division Duplexing) modes, allowing for synchronous data transmission with virtually no latency.
Plug-and-Play Deployment in the License-Free 24 GHz Band
The airFiber AF-24 operates in the worldwide, license-free 24 GHz frequency band, allowing for deployment almost anywhere without the need for special permits or licensing costs (subject to local regulations). The system is designed for easy installation; a single person can mount the unit, and a two-person crew can efficiently install and align a complete link. Its intuitive airOS™ Configuration Interface enables quick setup and deployment, minimizing downtime and labor costs.
Technical Specifications
| Operating Frequency | 24.05 – 24.25 GHz |
| Maximum Throughput | 1.5+ Gbps |
| Maximum Range | 13+ km |
| Packets per Second | > 1 Million |
| Encryption | 128-Bit AES |
| Latency | Full Duplex Mode: < 200 µs at Full Throughput |
| Modulation | 64QAM MIMO, 16QAM MIMO, QPSK MIMO, QPSK SISO |
| Antenna Gain | TX: 33 dBi, RX: 38 dBi |
| Beamwidth | < 3.5° |
| Dimensions | 649 x 426 x 303 mm (25.55 x 16.77 x 11.93") |
| Weight (Mount Included) | 10.5 kg (23.15 lb) |
| Max. Power Consumption | 50W |
| Power Supply | 50V, 1.2A PoE GigE Adapter (Included) |
| Power Method | Passive Power over Ethernet |
| Operating Temperature | -40 to 55° C (-40 to 131° F) |
| Wind Survivability | 200 km/hr (125 mph) |
| Certifications | CE, FCC, IC |
Manufacturer Technical Data
| Product Spec Sheet |
 Download |
|---|
