Ubiquiti
Ubiquiti UniFi Switch Ultra 8-Port Gigabit PoE+ Switch (52W)
Pickup available at NexGen Computing
Usually ready in 24 hours
Compact Powerhouse for Your Network Edge
Introducing the Ubiquiti UniFi Switch Ultra 60W, a compact and powerful Layer 2 Gigabit switch designed for ultimate versatility. This 8-port switch is the perfect solution for expanding network capacity and simplifying power delivery in residential installations, home offices, or small businesses. Its fanless, compact design allows for flexible, unobtrusive placement on a desktop or mounted on a wall.
Robust PoE+ for Demanding Devices
With the included 60W power adapter, the USW-Ultra-60W delivers a total of 52W of PoE power to your connected devices. It features seven Gigabit PoE+ (802.3at) output ports, capable of providing up to 30W of power per port, making it ideal for powering UniFi access points, IP cameras, and VoIP phones. The eighth port serves as a Gigabit uplink, which can also accept PoE++ input for alternative power options.
Seamless UniFi Integration and Management
As part of the UniFi ecosystem, the Switch Ultra is managed through the intuitive UniFi Network application (Version 8.0.7 and later). This powerful platform allows for centralized configuration, monitoring, and management of all your UniFi devices from a single interface. Benefit from a suite of advanced Layer 2 switching features, including port isolation, storm control, port mirroring, jumbo frames, and more to ensure peak network performance and security.
High-Performance Switching
Don't let its small size fool you. The UniFi Switch Ultra boasts a 16 Gbps switching capacity and an 8 Gbps total non-blocking throughput, ensuring smooth, congestion-free data flow across all connected devices, even in traffic-heavy environments.
Official Specifications
| Mechanical | |
|---|---|
| Dimensions | 203 x 76 x 33 mm (8 x 3 x 1.3") |
| Weight | Device: 320 g (11.3 oz) Wall Mount: 45 g (1.6 oz) 60W Adapter: 330 g (11.6 oz) |
| Enclosure Material | Polycarbonate |
| Hardware | |
| Networking Interface | (8) GbE RJ45 Ports |
| PoE Interface | (7) PoE/PoE+ (Pins 1, 2+; 3, 6-) |
| Management Interface | Ethernet In-Band |
| Total Non-Blocking Throughput | 8 Gbps |
| Switching Capacity | 16 Gbps |
| Power Method | 54V, 1.1A Power Adapter (Included) or PoE++ Input |
| Power Supply | External 60W AC/DC Adapter (Included) |
| Supported Voltage Range | 44—57V DC |
| Max. Power Consumption | 8W (Excluding PoE Output) |
| PoE | |
| Total Available PoE | 52W (with included 60W AC adapter) |
| Max. PoE+ Wattage per Port by PSE | 30W |
| Environmental | |
| Operating Temperature | -20 to 45° C (-4 to 113° F) with 60W AC adapter |
| Operating Humidity | 10 to 90% Noncondensing |
| Certifications | CE, FCC, IC |
| Software | |
| Management Application | UniFi Network (Version 8.0.7 and later) |
| Layer 2 Features | Port isolation, Storm control, Port mirroring, Flow control, Jumbo frames, Egress rate limit, and more. |
Manufacturer Technical Data
| Product Spec Sheet |
 Download |
|---|
