AJAX
AJAX MultiTransmitter Jeweller Wired Alarm Integration Module
Pickup available at NexGen Computing
Usually ready in 24 hours
Seamlessly Integrate Your Existing Wired Alarm into the AJAX Ecosystem
Give your wired security system a new lease on life with the AJAX MultiTransmitter Jeweller. This powerful integration module allows you to connect third-party wired detectors and devices to a modern Ajax security system. Now you can enjoy the advanced features of Ajax, including smartphone app control, detailed notifications, and automation scenarios, without having to replace your existing wired security equipment. The MultiTransmitter is the perfect solution for upgrading an outdated alarm system, providing a cost-effective path to a smarter, more reliable security setup.
Key Features:
- 18 Wired Zones: Connect a wide array of third-party wired devices, with support for NC, NO, EOL, 2EOL, and 3EOL connection types.
- Jeweller Communication Technology: Benefit from proprietary wireless communication that ensures secure, two-way communication with the Ajax hub over a long range. This technology includes block encryption with a dynamic key and frequency hopping to prevent jamming and interference.
- Informative Alarms: Receive instant, detailed notifications on your smartphone. You can specify the device name, alarm type, and location for each connected sensor, providing you with precise information in the event of an intrusion, fire, gas leak, and more.
- Remote Control and Configuration: Manage your entire security system, including the integrated wired devices, through the user-friendly Ajax app. Installers can also remotely configure settings via the PRO app.
- Advanced Anti-Sabotage: The MultiTransmitter is equipped with two tampers that protect it against dismantling and detachment from the wall, providing an extra layer of security.
- Backup Power Supply: The module is powered by a 100-240V mains supply and has space for a 12V backup battery (up to 7 Ah capacity), ensuring continuous operation during power outages.
Unlock the Full Potential of Your Security System
By integrating your existing wired detectors—such as perimeter IR sensors, gas detectors, and panic buttons—with the Ajax MultiTransmitter, you can create a comprehensive and robust security network. Set up automation scenarios to have your system react instantly to threats, such as automatically arming on a schedule or activating lights when a motion detector is triggered. Experience the peace of mind that comes with a modern, intelligent security system.
Technical Specifications
| Number of wired zones | 18 |
| Supported connection types | NC, NO, EOL, 2EOL, 3EOL |
| EOL resistance | From 1 kΩ to 15 kΩ for each resistor, up to 30 kΩ of total resistance (with firmware version 2.13 and higher) |
| Communication technology | Jeweller (866.0 – 926.5 MHz depending on region) |
| Maximum effective radiated power (ERP) | up to 20 mW |
| Radio signal range | Up to 6,500 ft (in open space) |
| Main power supply | 100–240 V~, 50/60 Hz |
| Backup power supply | 12 V⎓, up to 7 Ah capacity (battery not included) |
| Power supply for connected devices | 10.5–15 V, up to 1 A of total maximum current consumption |
| Operating temperature range | -10°C to +40°C (14°F to 104°F) |
| Operating humidity | Up to 75% |
| Protection class | IP40, IK06 |
| Dimensions | 192 × 238 × 100 mm (7.55″ × 9.37″ × 3.94″) |
| Weight | 802 g (28.29 oz) |
Manufacturer Technical Data
| Product Spec Sheet |
 Download |
|---|
