Mean Well
Mean Well - 15W Singe Output DC - DC Converter - 24VDC
Pickup available at NexGen Computing
Usually ready in 24 hours
Reliable Power Conversion for Demanding Applications
Introducing the Mean Well SD-15A-24, a robust and efficient 15-watt enclosed DC-DC converter designed to deliver a stable 24VDC output from a 12VDC input source. This high-reliability power supply is engineered for industrial applications, battery backup systems, and transportation vehicles where consistent and clean power is paramount. Its compact, chassis-mount design and wide 2:1 input voltage range make it a versatile solution for converting and regulating DC power.
Engineered for Performance and Safety
The SD-15A-24 is built with a comprehensive suite of protections to safeguard both the converter and your connected equipment. It features robust protection against short circuits, overload, and over-voltage conditions. With a built-in EMI filter, it minimizes ripple and noise, ensuring a clean and stable output. This converter operates efficiently across a wide temperature range from -10°C to +60°C and is constructed for long-term, dependable service, backed by a 2-year warranty.
Key Features:
- Stable 24V Output: Delivers a regulated 15W of power at 24VDC, 0.625A.
- Wide 12V Input Range: Accepts a 2:1 input range from 9.2 to 18VDC.
- Industrial Grade Protections: Fully protected against short circuit, overload (105-160%), and over voltage.
- High Reliability: Features a 100% full load burn-in test and is designed for longevity.
- Low Noise: Integrated EMI filter ensures low ripple and noise for sensitive electronics.
- Compact & Easy to Install: Enclosed chassis design with screw terminals for secure and straightforward installation.
Technical Specifications
| Specification | Details |
|---|---|
| Model | SD-15A-24 |
| Output | |
| DC Voltage | 24V |
| Rated Current | 0.625A |
| Rated Power | 15W |
| Ripple & Noise (max.) | 100mVp-p |
| Voltage Adj. Range | 21.6 ~ 26.4V |
| Input | |
| Voltage Range | 9.2 ~ 18VDC |
| Efficiency (Typ.) | 76% |
| Protection | |
| Overload | 105 ~ 160% rated output power. Protection type: Hiccup mode, recovers automatically after fault condition is removed. |
| Over Voltage | 27.6 ~ 32.4V. Protection type: Shut off o/p voltage, clamping by zener diode. |
| Environment | |
| Working Temperature | -10 ~ +60°C (Refer to derating curve) |
| Working Humidity | 20 ~ 90% RH non-condensing |
| Safety & EMC | |
| Withstand Voltage | I/P-O/P: 1.5KVAC, I/P-FG: 1KVAC, O/P-FG: 0.5KVAC |
| EMC Emission | Compliance to EN55022 (CISPR22) Class B |
| Physical | |
| Dimensions (L x W x H) | 78 x 51 x 28 mm |
| Weight | 180g |
Manufacturer Technical Data
| Product Spec Sheet |
 Download |
|---|
