Mean Well - 200W Single Output DC-DC Converter, INPUT: 19-36VDC (10.4Amp), OUTPUT: 48VDC (4.2Amp)
Pickup available at NexGen Computing
Usually ready in 24 hours
Robust & Reliable 200W DC-DC Power Conversion
Engineered for performance and reliability, the Mean Well SD-200B-48 is a high-efficiency, 200W enclosed-type DC-DC converter. This unit expertly converts a 24V DC input (ranging from 19-36VDC) into a stable, regulated 48V DC output, making it an ideal step-up or 'boost' converter for demanding industrial applications. Built with the quality Mean Well is known for, this converter ensures consistent power for your critical systems.
Core Features & Benefits
- Wide Input Range: The 2:1 wide input voltage range accommodates variations in the power source, providing operational flexibility.
- Comprehensive Protection: Equipped with built-in safeguards against short circuits, overload, over voltage, and over temperature to ensure longevity and protect connected equipment.
- High Efficiency: With an efficiency rating of 86%, this converter minimizes energy loss, reducing heat generation and operational costs.
- Reliable Cooling: Cooled by free air convection, it operates silently and reliably without the need for a fan across a wide temperature range of -20°C to +60°C.
- Isolation: Features 1500VAC I/O isolation to enhance safety and system integrity.
- Quality Assured: Undergoes a 100% full load burn-in test to guarantee performance right out of the box.
Technical Specifications
| OUTPUT | |
| DC Voltage | 48V |
| Rated Current | 4.2A |
| Current Range | 0 ~ 4.2A |
| Rated Power | 201.6W |
| Ripple & Noise (max.) | 200mVp-p |
| Voltage Adj. Range | 43 ~ 53VDC |
| Voltage Tolerance | ±1.0% |
| INPUT | |
| Voltage Range | 19 ~ 36VDC |
| Efficiency (Typ.) | 86% |
| DC Current (Typ.) | 10.4A |
| PROTECTION | |
| Overload | 105 ~ 135% rated output power. Protection type: Shut down o/p voltage, re-power on to recover. |
| Over Voltage | 53 ~ 65V. Protection type: Shut down o/p voltage, re-power on to recover. |
| Over Temperature | Protection type: Shut down o/p voltage, recovers automatically after temperature goes down. |
| ENVIRONMENT | |
| Working Temperature | -20 ~ +60°C (Refer to output load derating curve) |
| Working Humidity | 20 ~ 90% RH non-condensing |
| Storage Temp., Humidity | -40 ~ +85°C, 10 ~ 95% RH |
| SAFETY & EMC | |
| Withstand Voltage | I/P-O/P: 1.5KVAC, I/P-FG: 1.5KVAC, O/P-FG: 0.5KVAC |
| Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500VDC |
| EMC Emission | Compliance to EN55022 (CISPR22) Class B |
| EMC Immunity | Compliance to EN61000-4-2,3,4,6,8; ENV50204 |
| OTHERS | |
| Manufacturer Part Number | SD-200B-48 |
| Dimensions (L x W x H) | 215 x 115 x 50 mm |
| Weight | 1.1 Kg |
Manufacturer Technical Data
| Product Spec Sheet |
 Download |
|---|
