Milesight UR75 Industrial 5G Router with Wi-Fi 6, GPS, 4-Port PoE+
Pickup available at NexGen Computing
Usually ready in 24 hours
Harness Next-Generation Speed and Unbreakable Reliability
The Milesight UR75 is a high-performance, industrial-grade 5G router engineered for the most demanding M2M and IoT applications. This powerhouse device combines blazing-fast 5G connectivity with a rich feature set, including Wi-Fi 6, high-precision GPS, and four 802.3af/at Power over Ethernet (PoE) ports, to deliver ultra-reliable, high-speed data transmission for critical operations. Its rugged design and powerful quad-core processor ensure seamless performance in harsh environments, making it the ideal solution for smart grids, industrial automation, digital media installations, and remote telemetry.
Peak Performance and Connectivity
Powered by a quad-core ARM Cortex-A55 CPU, the UR75 provides the horsepower needed for complex data processing and transmission. It supports global 5G (NSA/SA) and 4G LTE networks, with dual SIM slots for automatic failover between carriers, guaranteeing uninterrupted connectivity. The inclusion of Wi-Fi 6 offers dual-band 2.4G & 5G concurrent connections with speeds up to 1.8 Gbps, while the five Gigabit Ethernet ports (1 WAN, 4 LAN) provide lightning-fast wired connections. Four of these LAN ports feature PoE+ functionality, simplifying installation by delivering both power and data to connected devices like IP cameras and sensors through a single cable.
Built for the Industrial Edge
The UR75 is designed to thrive where standard networking hardware fails. Its robust, IP30-rated metal housing and wide operating temperature range of -40°C to +70°C ensure dependable operation in extreme conditions. This router is packed with industrial-focused interfaces, including RS232 and RS485 serial ports for legacy equipment, and digital I/O (1x DI, 1x DO) for advanced machine-to-machine applications. The integrated high-precision GNSS (GPS, GLONASS, BDS, Galileo) allows for real-time location tracking of mobile assets.
Advanced Security and Management
Security is paramount in industrial networks. The UR75 offers robust protection with support for secure VPN tunnels like IPsec and OpenVPN. It also features a stateful firewall and multi-level user authority for comprehensive access control. For large-scale deployments, the Milesight DeviceHub provides a centralized platform for easy setup, mass configuration, and remote management, significantly reducing operational complexity.
Key Features:
- Global 5G Sub-6 (NSA/SA) and 4G LTE Connectivity
- High-Performance Quad-Core 2 GHz CPU
- Dual SIM Slots for Redundant Carrier Links
- 4 x 802.3 af/at PoE+ PSE LAN Ports
- Dual-Band Wi-Fi 6 (802.11ax) for High-Speed Wireless Access
- High-Precision GNSS: GPS, GLONASS, BDS, Galileo
- Rich Interfaces: RS232, RS485, Digital I/O
- Rugged IP30 Metal Enclosure with Wide Operating Temperature (-40°C to 70°C)
- Advanced Security with VPN and Firewall
- Centralized Remote Management via DeviceHub
Technical Specifications
| Hardware System | |
|---|---|
| CPU | Quad-core ARM Cortex-A55, 2 GHz |
| Memory | 1 GB LDDR4x RAM and 1 GB NAND Flash |
| Extendable Storage | 1 × M.2 NVMe SSD Interface |
| Cellular Interface | |
| Network | 5G NR (NSA & SA), 4G LTE, WCDMA |
| SIM Slot | 2 (Mini SIM-2FF) |
| Antenna | 4 × 50 Ω SMA Connectors (Female) |
| Ethernet Interface | |
| Ports | 5 × 10/100/1000 Mbps (1 WAN + 4 LAN) |
| PoE | 4 × 802.3 af/at PoE PSE on LAN Ports |
| Wi-Fi Interface | |
| Standards | IEEE 802.11a/b/g/n/ac/ax (Wi-Fi 6) |
| Max Bit Rate | 2.4 GHz: 600 Mbps, 5 GHz: 1200 Mbps |
| Antenna | 4 × 50 Ω SMA Connectors (RP-SMA Female) |
| GNSS | |
| Technology | GPS, GLONASS, BDS, Galileo, QZSS |
| Antenna | 1 × 50 Ω SMA Connector (SMA Female) |
| Interfaces | |
| Serial | 1 × RS232 + 1 × RS485 |
| DI/DO | 1 × DI + 1 × DO (Galvanic Isolation) |
| USB | 1 × USB 3.0 (Type-C) for power, network, and debug |
| Power Supply | |
| Power Input | 9-48 VDC (48V is required for PoE) |
| Physical Characteristics | |
| Ingress Protection | IP30 |
| Housing | Metal |
| Operating Temperature | -40°C to +70°C (-40°F to +158°F) |
| Mounting | DIN rail, wall or tabletop |
