RF Elements UltraDish TP 21 21dBi Parabolic Antenna with TwistPort Connector
Pickup available at NexGen Computing
Usually ready in 24 hours
High-Performance Connectivity with Superior Noise Rejection
The RF Elements UltraDish™ TP 21 is a high-gain parabolic dish antenna engineered for high-performance subscriber module applications. It excels at minimizing sidelobes and providing a stable gain across a wide frequency bandwidth, ensuring a dependable and robust wireless link. The antenna's design focuses on rejecting noise, which results in a lower noise floor, higher signal-to-noise ratio, and ultimately, greater throughput and reliability for your network.
Revolutionary TwistPort™ Connector
Featuring RF Elements' proprietary TwistPort™ waveguide connector, the UltraDish™ TP 21 offers a groundbreaking approach to radio connection. This quick-locking port ensures a lossless connection and makes radio installation and replacement incredibly intuitive and easy. The smart "twist and lock" design allows for single-handed radio mounting, streamlining deployments and maintenance.
Built for Durability and Versatility
Constructed from high-quality, UV-resistant ABS plastic, polycarbonate, and a lightweight aluminum reflector, the UltraDish™ TP 21 is built to withstand harsh environmental conditions. It boasts an IP65 environmental rating and can survive winds up to 160 km/h. The massive, innovative mount provides an improved grip and supports a wide range of pole diameters (40-80mm), making deployment both easy and versatile. Additionally, the stainless steel hardware features a black coating to prevent seizing during installation.
Ultra-Wideband Performance
Stable antenna gain is crucial for reliable link performance. The UltraDish™ TP 21 delivers consistent gain across an ultra-wideband spectrum from 5180 MHz to 6775 MHz. This allows network operators to leverage the entire 5 and 6 GHz spectrum with confidence, ensuring stable performance regardless of the channel used.
Technical Specifications
| Performance | |
|---|---|
| Antenna Type | Parabolic Dish |
| Frequency Range | 5180 - 6775 MHz |
| Gain | 21.2 dBi |
| Azimuth Beam Width -3 dB | H 10° / V 9° |
| Elevation Beam Width -3 dB | H 9° / V 10° |
| Azimuth Beam Width -6 dB | H 14° / V 13° |
| Elevation Beam Width -6 dB | H 13° / V 14° |
| Front-to-Back Ratio (Min) | 28 dB |
| Physical | |
| Antenna Connection | TwistPort™ - Quick Locking Waveguide Port |
| Materials | UV Resistant ABS Plastic, Polycarbonate, Aluminium, Stainless Steel |
| Pole Mounting Diameter | 40 - 80 mm |
| Dimensions | 465 x 345 x 263 mm (18.3 x 13.6 x 10.4 inches) |
| Environmental & Compatibility | |
| Environmental Rating | IP65 |
| Operating Temperature | -40°C to +60°C (-40°F to +140°F) |
| Wind Survival | 160 km/h |
| Wind Loading | 115 N at 160 km/h |
| Compatible Platforms | Any TwistPort™ Adaptor; Any SIMPER™ Radio |
