TP-Link
TP-Link Omada SG5452XMPP 48-Port Gigabit L3 Managed PoE++ Switch with 10G Uplinks
Pickup available at NexGen Computing
Usually ready in 24 hours
High-Power, High-Speed Enterprise Switching for Demanding Networks
Elevate your business network with the TP-Link Omada SG5452XMPP, a robust Layer 3 managed switch designed for the access layer. This high-performance switch is engineered to power a multitude of devices with its substantial 770W total PoE budget, making it ideal for deploying Wi-Fi 6 access points, 4K surveillance cameras, and VoIP phone systems without the need for additional power infrastructure. With a combination of 8 PoE++ ports delivering up to 90W each and 40 PoE+ ports, it offers unparalleled flexibility for both current and future high-power devices. Lightning-fast 10 Gbps SFP+ slots eliminate network bottlenecks, while physical stacking and advanced L3 features provide the scalability, redundancy, and efficiency required for modern enterprise environments.
Centralized Management and Advanced Capabilities
As part of the Omada Software Defined Networking (SDN) platform, the SG5452XMPP allows for 100% centralized cloud management through a single interface, integrating seamlessly with other Omada access points, switches, and gateways. This simplifies network administration, enabling zero-touch provisioning and intelligent monitoring. For networks that require advanced segmentation and traffic management, its Lite L3 features, including RIP, OSPF, and Static Routing, provide efficient routing capabilities. Features like Perpetual and Fast PoE ensure that connected devices remain powered during switch reboots, maximizing uptime for critical applications.
Built for Reliability and Performance
The SG5452XMPP is built for performance, offering a switching capacity of up to 176 Gbps per unit. Physical stacking of up to four units creates a simplified and resilient network architecture with built-in redundancy. Robust security strategies, including Access Control Lists (ACL), Port Security, and 802.1X authentication, safeguard your network from threats. Whether managed centrally via the Omada SDN controller or as a standalone unit through a web GUI or CLI, this switch provides a powerful and reliable foundation for small to medium-sized businesses, ISPs, and hospitality venues.
Comprehensive Specifications
| Hardware Features & Performance | |
|---|---|
| Interface | • 48× 10/100/1000 Mbps RJ45 Ports • 4× 1/10 Gbps SFP+ Slots • 1× RJ45 Console Port • 1× USB Type-C Console Port • 1× USB 2.0 Port |
| Fan Quantity | 3 |
| Power Supply | 100-240 V~ 50/60 Hz |
| Switching Capacity | 176 Gbps |
| Packet Forwarding Rate | 130.9 Mpps |
| MAC Address Table | 32K |
| Jumbo Frame | 9 KB |
| Power over Ethernet (PoE) | |
| PoE Standard | 802.3af/at/bt compliant |
| PoE Ports | • PoE++ Ports: 8 Ports (Ports 1-8), up to 90W per port • PoE+ Ports: 40 Ports (Ports 9-48), up to 30W per port |
| PoE Power Budget | 770W |
| PoE Features | Perpetual PoE & Fast PoE |
| Physical Stacking | |
| Max Stackable Units | 4 |
| Stacking Port | 10G SFP+ Slots |
| Stacking Bandwidth | Up to 40 Gbps (with 2 stacking ports) |
| Software Features | |
| L3 Features | • Static Routing • RIP • OSPF • DHCP Server/Relay |
| Security | • Access Control List (ACL) • Port Security • DoS Defend • 802.1X Authentication • IP/MAC-Port Binding |
| Management | • Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller • Web-based GUI • Command Line Interface (CLI) • SNMP v1/v2c/v3 • RMON |
| Physical & Environmental | |
| Dimensions (W x D x H) | 17.3 × 13.0 × 1.7 in (440 × 330 × 44 mm) |
| Mounting | Rack Mountable |
| Operating Temperature | 0–45 ℃ (32–113 ℉) |
Manufacturer Technical Data
| Product Spec Sheet |
 Download |
|---|
