TP-Link
TP-Link Omada SDN 5-Port Gigabit Smart Managed Switch
Pickup available at NexGen Computing
Usually ready in 24 hours
Centralize Your Network with Full Gigabit Speeds & Cloud Management
Upgrade your network infrastructure with the TP-Link Omada 5-Port Gigabit Smart Managed Switch. This high-performance switch is engineered for efficiency, security, and centralized management, making it the perfect solution for business and advanced home networks. As part of the Omada Software Defined Networking (SDN) platform, it offers 100% centralized cloud management for ultimate control and scalability. Manage your entire network from a single interface, anytime, anywhere.
Robust Security and Advanced L2+ Features
This switch is packed with a comprehensive suite of L2 and L2+ features. Implement robust security strategies with features like IP-MAC-Port Binding, Access Control List (ACL), Port Security, and Storm Control to defend against a variety of network threats. Enhance network performance and organization by utilizing 802.1Q VLAN, Quality of Service (QoS) for traffic prioritization, and IGMP Snooping to optimize multicast traffic. Static Routing allows for internal traffic routing, ensuring more efficient use of network resources.
Flexible Deployment and Power over Ethernet (PoE) Passthrough
Designed for versatile deployment, this model features innovative PoE Passthrough technology. It can be powered by a PoE source (802.3af/at/bt) and simultaneously power other PoE devices. It includes one Gigabit PoE++ input port and four Gigabit PoE+ output ports, capable of delivering up to a 64W total power budget. This unique capability simplifies installations in locations without direct access to power outlets and can even extend the standard 100-meter PoE distance up to 200 meters, ideal for deploying long-range IP cameras and access points.
Built for Demanding Environments
Engineered for reliability, the switch is housed in a durable, IP55-rated weatherproof enclosure that protects it from dust and water ingress. It is also UV-resistant and features 4KV lightning protection, ensuring stable operation in harsh outdoor conditions with a wide operating temperature range of -40 to 60 °C.
| Hardware Features | |
|---|---|
| Interface | 5 x 10/100/1000Mbps RJ45 Ports (Port 5 supports PoE++ In, Ports 1-4 support PoE+ Out) |
| Standards and Protocols | IEEE 802.3i, 802.3u, 802.3ab, 802.3ad, 802.3af, 802.3at, 802.3bt, 802.3x, 802.1d, 802.1s, 802.1w, 802.1q, 802.1p, 802.1x |
| PoE Ports | Port 5 (PoE In): 802.3af/at/bt Ports 1-4 (PoE Out): 802.3af/at, Passthrough |
| PoE Power Budget | Up to 64W (when powered by 802.3bt Type 4) |
| Dimensions (W x D x H) | 8.37 x 8.25 x 2.81 inches |
| Mounting | Wall/Pole Mountable |
| Performance | |
| Switching Capacity | 10 Gbps |
| Packet Forwarding Rate | 7.44 Mpps |
| MAC Address Table | 8K |
| Jumbo Frame | 9 KB |
| Software Features | |
| Quality of Service (QoS) | 802.1p CoS/DSCP priority, 8 priority queues, Priority Schedule Mode (SP, WRR, SP+WRR), Port/Flow-based Rate Limiting, Voice VLAN |
| L2 and L2+ Features | Static Routing, DHCP Relay, IGMP Snooping, L2/L3/L4 QoS, ACL, Link Aggregation (LACP), STP/RSTP/MSTP, Loopback Detection |
| VLAN | Supports up to 4K VLANs simultaneously, Port/MAC/Protocol-based VLAN, Voice VLAN |
| Security | IP-MAC-Port Binding, AAA, Port Security, Storm Control, DHCP Snooping, IP Source Guard, SSL, SSH, DoS Defend |
| Management | Omada App, Centralized Management (Omada Hardware/Software Controller, Cloud-Based Controller), Web GUI, CLI, SNMP, RMON |
| Others | |
| Certifications | CE, FCC, RoHS |
| Package Contents | TP-Link Omada 5-Port Gigabit Switch, Mounting Kits, Installation Guide |
| Environment | Operating Temperature: -40°C to 60°C (-40°F to 140°F) Storage Temperature: -40°C to 70°C (-40°F to 158°F) |
Manufacturer Technical Data
| Product Spec Sheet |
 Download |
|---|
