Ubiquiti
Ubiquiti UniFi 10GbE WAN Aggregation Switch
Pickup available at NexGen Computing
Usually ready in 24 hours
Ensure Uninterrupted Network Performance with 10Gbps WAN Redundancy
The Ubiquiti UniFi WAN Switch is a high-performance 10GbE Layer 2 switch engineered for mission-critical networks that demand constant connectivity. It serves as the crucial link between your ISP and two UniFi Cloud Gateways, enabling automatic failover to a standby gateway if the primary unit goes offline. This is achieved through UniFi's innovative Shadow Mode, which provides seamless high-availability to ensure your network remains operational without interruption. With its robust hardware and integration into the UniFi ecosystem, this switch is the ideal solution for enterprises requiring maximum uptime.
High-Speed Connectivity and Resilient Power
Designed for modern high-speed internet connections, the UniFi WAN Switch features three 10GbE RJ45 ports and a dedicated 1GbE RJ45 port for management. It boasts a 20 Gbps switching capacity and a 10 Gbps total non-blocking throughput, ensuring your network can handle demanding traffic without bottlenecks. To further enhance reliability, the switch is equipped with dual, redundant AC power supply inputs, safeguarding against power supply failure and maintaining continuous operation.
Centralized Management with UniFi Network
Like all UniFi devices, the USW-WAN-RJ45 is managed through the intuitive UniFi Network application. This powerful platform allows for centralized configuration, monitoring, and management of your entire network infrastructure from a single interface. The 1U rack-mountable design allows for clean and simple integration into your existing network rack.
Technical Specifications
| Category | Specification |
| Mechanical | |
| Dimensions | 442.4 x 120 x 43.7 mm (17.4 x 4.72 x 1.7") |
| Weight | Without mounting brackets: 2.3 kg (5.1 lb) With mounting brackets: 2.4 kg (5.3 lb) |
| Enclosure Material | SGCC Steel |
| Hardware | |
| Networking Interfaces | (3) 10G/5G/2.5G/1G/100M RJ45 Ports (1) 1G/100M/10M RJ45 Port |
| Management Interface | Ethernet |
| Switching Capacity | 20 Gbps |
| Total Non-Blocking Throughput | 10 Gbps |
| Forwarding Rate | 15 Mpps |
| Power Method | (2) Universal AC input, 100-240V AC, 50/60 Hz |
| Power Supply | (2) AC/DC, Internal, 36W |
| Max. Power Consumption | 18W |
| ESD/EMP Protection | Air: ± 16kV, Contact: ± 10kV |
| LEDs | System, Ethernet |
| Environmental | |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 10 to 90% Noncondensing |
| Software | |
| Application Requirements | UniFi Network Version 9.1.120 or later |
| Certifications | CE, FCC, IC |
Manufacturer Technical Data
| Product Spec Sheet | Not available for this product |
|---|
