VSOL V2801RD Dual-Mode xPON ONU
Pickup available at NexGen Computing
Usually ready in 24 hours
Unlock Superior Fiber Optic Performance
Experience a new level of reliability and speed with the VSOL V2801RD, a single-port xPON Optical Network Unit (ONU) engineered for excellence in FTTH (Fibre-to-the-Home) and FTTB (Fibre-to-the-Building) applications. This device is your gateway to high-speed data services, designed to meet the demanding needs of telecom operators and home users alike. Its core strength lies in its auto-adaptive capability, allowing it to seamlessly function in both GPON and EPON networks without any manual configuration. This dual-mode functionality ensures broad compatibility with mainstream Optical Line Terminals (OLTs) from leading manufacturers like Huawei, ZTE, and Fiberhome.
Robust, Secure, and Easy to Manage
The V2801RD is built on a foundation of high-performance chip technology, supporting both Layer 2 and Layer 3 functions to deliver carrier-grade data services. Security is paramount, and this ONU delivers with a powerful firewall, offering protection against DDOS attacks and filtering based on ACL/MAC/URL. It also features advanced protection against abnormal network activity, with the ability to detect Rogue ONUs and support for Hardware Dying Gasp. Management is made simple through a variety of protocols, including WEB, TELNET, OAM (OMCI), and TR069, giving administrators flexible options for configuration, monitoring, and troubleshooting.
Designed for Demanding Environments
With its compact design and high reliability, the V2801RD is suitable for a wide range of deployment scenarios, including office (FTTO), desktop (FTTD), and home (FTTH) broadband access, as well as video surveillance. It is engineered to operate in a wide temperature environment, ensuring consistent performance when it matters most. The inclusion of a Gigabit Ethernet port ensures that you can take full advantage of the high-speed fiber connection.
Technical Specifications
| Interface Parameters | |
| PON Interface | 1 x XPON port (EPON PX20+ & GPON Class B+) SC single mode, SC/UPC connector TX optical power: 0～+4dBm RX sensitivity: -27dBm Overload optical power: -3dBm(EPON) or -8dBm(GPON) Transmission distance: 20KM Wavelength: TX 1310nm, RX 1490nm |
| LAN Interface | 1 x GE, Auto-negotiation RJ45 connectors |
| Functional Data | |
| XPON Mode | Dual mode, Auto-access to EPON/GPON OLT |
| Uplink Mode | Bridging and Routing Mode |
| Abnormal Protection | Detecting Rogue ONU, Hardware Dying Gasp |
| Firewall | DDOS, Filtering Based on ACL/MAC/URL |
| Hardware Parameters | |
| Operating Condition | Operating temp: -30 ~ +60°C; Operating humidity: 10 ~ 90% (non-condensing) |
| Storing Condition | Storing temp: -30 ~ +70°C; Storing humidity: 10 ~ 90% (non-condensing) |
| Power Adapter | DC 12V, 0.5A, external AC-DC power adaptor |
| Power Supply | ≤4W |
| Indicators | SYS, LINK/ACT, REG |
| Physical Specifications | |
| Dimensions (L×W×H) | 82mm × 82mm × 25mm |
| Net Weight | 0.085Kg |
